FLANGE PN16 51 SB 1.4404 E

FLANGE PN16 51 SB 1.4404 E - ISO EN 10357-D WxW FLANGE COMPLETE WITH 4xM8 EPDM
Manufacturer: Alfa Laval
Product code: 5058
Item number: 9612498712
In stock:
The green marker indicates that the product is typically in stock. The yellow marker indicates that the product typically has a little longer lead time
HS Code:73072980
Delivery time:1-3 days
  • Range: Flanges
  • Product Model: ISO EN 10357-D Pressure Flanges
  • Size: 51.0 mm
  • Material: 1.4404/EPDM
  • Finish: SB (ID=0.8/OD=1.0)
  • Connection Type: Weld ends
  • Standard: ISO 2037
  • Design: Complete
  • Item Weight: 2.49
Price:
Login to view price
A: 3.90
B: 1.97
C: 4.00 x M8
OD/ID x t: 51.00/48.60 x 1.20
Pressure class PN (Bar): 16
