BEND-90 38-SHORT-POL/RAW-316L

BEND-90 38-SHORT-POL/RAW-316L - 1.5XD-ISO2037
Manufacturer: Alfa Laval
Product code: 5004
Item number: 9613404208
In stock:
The green marker indicates that the product is typically in stock. The yellow marker indicates that the product typically has a little longer lead time
HS Code:73072310
Delivery time:On request
  • Range: Bends
  • Product Model: ISO EN 10357-D Bends 90
  • Size: 38.0 mm
  • Material: 1.4404 (316L)
  • Finish: ID:RAW=0.8/OD:POL=1.0
  • Connection Type: Weld ends
  • Standard: ISO 2037
  • Design: 1.5xD Short
  • Item Weight: 0.22
Price:
Login to view price
L: 2.24
R (mm): 2.24
OD/ID x t: 38.00/35.60 x 1.20
OD1/ID1 x t1: 38.00/35.60 x 1.20
