BEND-90 101.6-SHORT-POL/RAW

BEND-90 101.6-SHORT-POL/RAW - 316L-1.5XD-ISO2037
Manufacturer: Alfa Laval
Product code: 5004
Item number: 9613404212
In stock:
The green marker indicates that the product is typically in stock. The yellow marker indicates that the product typically has a little longer lead time
HS Code:73072310
Delivery time:On request
  • Range: Bends
  • Product Model: ISO EN 10357-D Bends 90
  • Size: 101.6 mm
  • Material: 1.4404 (316L)
  • Finish: ID:RAW=0.8/OD:POL=1.0
  • Connection Type: Weld ends
  • Standard: ISO 2037
  • Design: 1.5xD Short
  • Item Weight: 2.43
Price:
Login to view price
L: 5.98
R (mm): 6.00
OD/ID x t: 101.60/97.60 x 2.00
OD1/ID1 x t1: 101.60/97.60 x 2.00
